DIN7500 DIN7500-EE Taptite Screws Fasteners Hexagon Cheese Head Thread Rolling Screws

  • DIN7500 DIN7500-EE Taptite Screws Fasteners Hexagon Cheese Head Thread Rolling Screws
  • DIN7500 DIN7500-EE Taptite Screws Fasteners Hexagon Cheese Head Thread Rolling Screws
  • DIN7500 DIN7500-EE Taptite Screws Fasteners Hexagon Cheese Head Thread Rolling Screws
  • DIN7500 DIN7500-EE Taptite Screws Fasteners Hexagon Cheese Head Thread Rolling Screws
Place of Origin JIANG SU PROVINCE CHINA
Brand Name YingYan
Certification ISO9000
Model Number M6
Minimum Order Quantity 1000pieces
Price Negotiable
Packaging Details Small Boxes, Plastic Bags, Bulk in Cartons,

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Hex Socket Cone Point Set Screw Grub Screw Standard GB/DIN/ASME/EN/ISO&etc.
Materials Carbon Steel/stainless Steel, Etc Surface Treatment Dacromet,Zinc Plated
Color Black,Blue-White,Silver Size M6/accroding Your Requirements
Length 12mm-16mm/accroding Your Requirements
Highlight

Taptite Screws Fasteners

,

Hexagon Cheese Head Screws Fasteners

,

DIN7500 Thread Rolling Screws
Leave a Message
Product Description

DIN7500 DIN7500-EE Carbon Steel And Stainless Steel Taptite Screws Hexagon Cheese Head Thread Rolling Screws



DIN7500 DIN7500-EE Taptite Screws Fasteners Hexagon Cheese Head Thread Rolling Screws 0

Thread Size
d
M2 M2.5 M3 M4 M5 M6 M8 M10 M12
P Pitch
b Ref.
dk Max. Plain Head
Knurled Heads
min
k max
min
s max
min
t min
0.4 0.45 0.5 0.7 0.8 1 1.25 1.5 1.75
16 17 18 20 22 24 28 32 36
3.8 4.5 5.5 7 8.5 10 13 16 18
3.98 4.68 5.68 7.22 8.72 10.22 13.27 16.27 18.27
3.62 4.32 5.32 6.78 8.28 9.78 12.73 15.73 17.73
2 2.5 3 4 5 6 8 10 12
1.86 2.36 2.86 3.82 4.82 5.7 7.64 9.64 11.57
1.58 2.08 2.58 3.08 4.095 5.14 6.14 8.175 10.175
1.52 2.02 2.52 3.02 4.02 5.02 6.02 8.025 10.025
1 1.1 1.3 2 2.5 3 4 5 6

Features:

Hexagon cheese head thread rolling screws possess a unique design that combines a hexagonal shank for ease of use with a cheese head, which is characterized by its rounded top and tapered sides. This design offers several distinct advantages over traditional screw types.

Advantages:

  1. The standard hexagonal head design allows for efficient tightening and loosening with a wrench or pliers, making the installation and removal process quick and effortless.
  2. The use of thread rolling screw technology creates stronger threads compared to traditional cut threads, resulting in superior thread strength and a more secure and reliable fastening effect.
  3. The thread rolling process, which causes less material fatigue compared to cutting, is employed to increase the overall durability of the screw.
  4. The cheese head design boasts a larger bearing surface, which increases the contact area with the connected parts, enabling better distribution of loads and reducing the risk of stripping or breaking.

Application Scenarios:

Hexagon cheese head thread rolling screws are commonly used in a wide range of applications where strength, durability, and ease of installation are critical. Some common applications include:

  1. Automotive Industry: For fastening components such as body panels, engine parts, and suspension systems.
  2. Machinery and Equipment: For assembly and fastening of various machine parts and components.
  3. Furniture and Cabinetry: For joining and securing pieces of furniture, cabinets, and other woodworking projects.
  4. Electronics and Appliances: For securing internal components and parts in electronic devices and appliances.
