Product Details
Name Hex Socket Cone Point Set Screw Grub Screw Standard GB/DIN/ASME/EN/ISO&etc.
Surface Treatment Plain, Black, Zinc Plated，Dacromet/according To Your Requirement Grade 10.9,12.9,etc.
Color Black,Blue,Silver Materials Carbon Steel/stainless Steel, Etc
Size Accroding Your Requirements Length Accroding Your Requirements
Highlight

High Strength Screw Fasteners

,

Hex Socket Cone Point Set Screw

,

Steel Grub Screw Fasteners
Leave a Message
Product Description

High Strength Fastener DIN914 DIN913 Steel Hex Socket Cone Point Set Screw Grub Screw

Features:

Hexagon socket set screws, also known as Allen screws or hex keys, are characterized by their hexagonal socket heads. This design allows for precise tightening and loosening using a hex key or Allen wrench. The screws typically have a smooth shank without threads, making them ideal for applications where a tight fit is needed without generating thread stress.

Advantages:

  1. Precision Fit: The hexagon socket design ensures a precise and secure fit, minimizing the risk of slippage or cam-out.
  2. Easy Installation and Removal: Using a hex key or Allen wrench, installation and removal of these screws are quick and effortless.
  3. High Torque Transmission: The hexagonal socket allows for efficient torque transmission, ensuring a tight and reliable fastening.
  4. Low Thread Stress: The smooth shank design eliminates the need for threads, reducing stress on the material and increasing durability.

Application Scenarios:

Hexagon socket set screws are commonly used in a variety of applications where precision and reliability are crucial. Some common applications include:

  1. Machine Assembly: For securing and adjusting parts and components in machines and equipment.
  2. Electronics and Appliances: For fastening internal components in electronic devices and appliances.
  3. Furniture and Fixtures: For joining and securing pieces of furniture, cabinets, and other fixtures.
  4. Automotive Industry: For fastening components in vehicles, such as interior trim, dashboards, and other assemblies.

DIN913 DIN914

High Strength Grub Screw Fasteners DIN914 DIN913 Steel Hex Socket Cone Point Set Screw 0

Screw Thread
d
M1.4 M1.6 (M1.8) M2 M2.5 M3 M4 M5 M6
P Pitch
dp max
min
e min
s Nominal Size
max
min
t min short
long
L0 ① Nominal Size
0.3 0.35 0.35 0.4 0.45 0.5 0.7 0.8 1
0.7 0.8 0.9 1 1.5 2 2.5 3.5 4
0.45 0.55 0.65 0.75 1.25 1.75 2.25 3.2 3.7
0.803 0.803 0.803 1.003 1.427 1.73 2.3 2.87 3.44
0.7 0.7 0.7 0.9 1.3 1.5 2 2.5 3
0.724 0.724 0.724 0.902 1.295 1.545 2.045 2.56 3.08
0.711 0.711 0.711 0.889 1.27 1.52 2.02 2.52 3.02
0.6 0.7 0.8 0.8 1.2 1.2 1.5 2 2
1.4 1.5 1.6 1.7 2 2 2.5 3 3.5
2 2.5 2.5 3 3 4 5 6 6
Weight of per 1000 steel products(≈kg)
- - - - - - - - -
Screw Thread
d
M8 M10 M12 (M14) M16 (M18) M20 (M22) M24
P Pitch
dp max
min
e min
s Nominal Size
max
min
t min short
long
L0 ① Nominal Size
1.25 1.5 1.75 2 2 2.5 2.5 2.5 3
5.5 7 8.5 10 12 13 15 17 18
5.2 6.64 8.14 9.64 11.57 12.57 14.57 16.57 17.57
4.58 5.72 6.86 6.86 9.15 11.43 11.43 13.72 13.72
4 5 6 6 8 10 10 12 12
4.095 5.095 6.095 6.095 8.115 10.115 10.115 12.142 12.142
4.02 5.02 6.02 6.02 8.025 10.025 10.025 12.032 12.032
3 4 4.8 5.6 6.4 7.2 8 9 10
5 6 8 9 10 11 12 13.5 15
6 8 12 14 16 16 16 18 20
Weight of per 1000 steel products(≈kg)
- - - - - - - - -



High Strength Grub Screw Fasteners DIN914 DIN913 Steel Hex Socket Cone Point Set Screw 1

Screw Thread
d
M1.4 M1.6 (M1.8) M2 M2.5 M3 M4 M5 M6
P Pitch
dt max
min
e min
s Nominal Size
max
min
t min short
long
L0 ② Nominal Size
0.3 0.35 0.35 0.4 0.45 0.5 0.7 0.8 1
- - - - - - - - 1.5
- - - - - - - - 0.9
0.803 0.803 0.803 1.003 1.427 1.73 2.3 2.87 3.44
0.7 0.7 0.7 0.9 1.3 1.5 2 2.5 3
0.724 0.724 0.724 0.902 1.295 1.545 2.045 2.56 3.08
0.711 0.711 0.711 0.889 1.27 1.52 2.02 2.52 3.02
0.6 0.7 0.8 0.8 1.2 1.2 1.5 2 2
1.4 1.5 1.6 1.7 2 2 2.5 3 3.5
2 2.5 2.5 2.5 3 3 4 5 6
Weight of per 1000 steel products(≈kg)
- - - - - - - - -
Screw Thread
d
M8 M10 M12 (M14) M16 (M18) M20 (M22) M24
P Pitch
dt max
min
e min
s Nominal Size
max
min
t min short
long
L0 ② Nominal Size
1.25 1.5 1.75 2 2 2.5 2.5 2.5 3
2 2.5 3 4 4 5 5 6 6
1.4 1.9 2.4 3.25 3.25 4.25 4.25 5.25 5.25
4.58 5.72 6.86 6.86 9.15 11.43 11.43 13.72 13.72
4 5 6 6 8 10 10 12 12
4.095 5.095 6.095 6.095 8.115 10.115 10.115 12.142 12.142
4.02 5.02 6.02 6.02 8.025 10.025 10.025 12.032 12.032
3 4 4.5 5.6 6.4 7.2 8 9 10
5 6 8 9 10 11 12 13.5 15
8 10 12 12 16 18 18 25 25
Weight of per 1000 steel products(≈kg)
- - - - - - - - -
