Carbon Steel Q235 / 35K Hexagon Flange Nuts Galvanization Din 6923 ISO 4161

  • Carbon Steel Q235 / 35K Hexagon Flange Nuts Galvanization Din 6923 ISO 4161
  • Carbon Steel Q235 / 35K Hexagon Flange Nuts Galvanization Din 6923 ISO 4161
  • Carbon Steel Q235 / 35K Hexagon Flange Nuts Galvanization Din 6923 ISO 4161
Place of Origin JIANG SU PROVINCE CHINA
Brand Name YingYan
Certification ISO9000
Model Number M3~M16
Minimum Order Quantity 1000piece
Price Negotiable
Packaging Details Small Boxes, Plastic Bags, Bulk in Cartons,

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Hexagon Flange Nuts Standard GB/DIN/ASME/EN/ISO&etc.
Material Carbon Steel Q195/35K Surface Treatment Zinc Plated
Color Blue-White Grade 4 , 8
Size M3-M16/according To Your Requirements
Highlight

Carbon Steel Q235 Hexagon Flange Nuts

,

Din 6923 Hexagon Flange Nuts

,

Flange Hexagon Nut
Leave a Message
Product Description

Din 6923 ISO 4161 Hexagon Flange Nuts Carbon Steel Q235/35K Galvanization Class4 , 8

Characteristics, Advantages, and Uses of DIN6923 Hexagon Flange Nuts (Carbon)

Characteristics:

  1. Standardized Design: DIN6923 flange nuts adhere to the DIN6923 standard, ensuring product uniformity and interchangeability.
  2. High-Strength Material: Made from high-strength materials like carbon steel, ensuring the nut's durability and strength.
  3. Flange Design: The nut features a flange at its base, increasing the contact area with the connected piece, thus improving connection stability and torque distribution.
  4. Multiple Strength Grades: Available in different strength grades like 4.8, 8.8, 10.9, and 12.9 to cater to various application needs.

Advantages:

  1. Efficient Connection: The flange design allows the nut to more efficiently distribute force across the connected piece, enhancing reliability and stability.
  2. Wide Applicability: The choice of different strength grades makes these nuts suitable for multiple application scenarios.
  3. Durability: Made from high-strength materials, ensuring a long lifespan and excellent durability.
  4. Easy Installation: The standardized design simplifies and speeds up the installation process.

Uses:

  1. Mechanical Equipment Connection: Ideal for connecting and securing various mechanical equipment, ensuring stable and safe operation.
  2. Building Structure Connection: In the construction sector, these nuts can be used to connect steel structures or secure other architectural elements, enhancing structural stability.
  3. Automotive Manufacturing: Widely used in the automotive industry for connecting and fastening parts like car bodies and engines.
  4. Other Industrial Fields: Due to their high strength and versatility, DIN6923 Hexagon flange nuts (Carbon) are also extensively used in other industries like shipping, aerospace, and more.

Overall, DIN6923 Hexagon flange nuts (Carbon), with their standardized design, high strength, and wide applicability, are essential fasteners in various industrial sectors.



Carbon Steel Q235 / 35K Hexagon Flange Nuts Galvanization Din 6923 ISO 4161 0

Thread Size
D
M5 M6 M8 M10 M12 M14 M16 M20
P Pitch Coarse thread
Fine thread 1
Fine thread 2
c min
da min
max
dc max
dw min
e min
m max
min
mw min
s max=nominal size
min
r max
0.8 1 1.25 1.5 1.75 2 2 2.5
/ / 1 1.25 1.5 1.5 1.5 1.5
/ / / (1.0) (1.25) / / /
1 1.1 1.2 1.5 1.8 2.1 2.4 3
5 6 8 10 12 14 16 20
5.75 6.75 8.75 10.8 13 15.1 17.3 21.6
11.8 14.2 17.9 21.8 26 29.9 34.5 42.8
9.8 12.2 15.8 19.6 23.8 27.6 31.9 39.9
8.79 11.05 14.38 16.64 20.03 23.36 26.75 32.95
5 6 8 10 12 14 16 20
4.7 5.7 7.6 9.6 11.6 13.3 15.3 18.9
2.2 3.1 4.5 5.5 6.7 7.8 9 11.1
8 10 13 15 18 21 24 30
7.78 9.78 12.73 14.73 17.73 20.67 23.67 29.67
0.3 0.36 0.48 0.6 0.72 0.88 0.96 1.2
